HT06Y-350/550/750

Purpose-Built Heavy-Duty Turning Solutions for Industrial Applications

Designed specifically for demanding metalworking environments, the HT06Y-350/550/750 serves as a robust addition to any facility requiring high-torque, large-part processing. It targets engineering teams and manufacturers focusing on long, heavy shafts and discs that necessitate rigid, precise turning operations. As a product from leading cnc turning manufacturers, it aligns with facility needs for CNC machines that can handle substantial workpieces while maintaining accuracy over extended production cycles. Its scalability, with options for various machining lengths, further suits shops optimizing workflow for medium to large batch sizes.

Advanced Structural and Drive Feature Integration Ensures Precision

The machine utilizes an integrally cast tailstock and sub-spindle rail combined with a reinforced bed featuring FEM-optimized ribs, enhancing rigidity and vibration dampening crucial for heavy cutting tasks. The 45° inclined saddle equipped with large roller linear guides and precision-grade ball screws ensures sustained bed accuracy during long production runs. Technical specifications such as a 4000 rpm spindle with 7.5/11 kW power, 72 mm spindle bore, and hydraulic 10” chuck emphasize its capability to deliver high spindle torque and speed. Furthermore, interpolated ±55 mm Y-axis movement and a servo tool turret with 12 or 16 stations allow complex multi-axis turning and milling, maximizing the machine’s versatility among cnc machines.

Operational Versatility in Various Heavy Manufacturing Environments

This CNC lathe excels in applications involving large disc and shaft turning, where durability and precision are critical. Industries such as automotive components, heavy machinery parts, and energy sector fabrication rely on the HT06Y-350/550/750 to achieve consistent machining quality for continuous production runs. Its Turn-Mill capability expands its utility, allowing simultaneous turning and milling operations that reduce cycle times and part handling. The programmable tailstock increases setup flexibility for lengthy workpieces and complex geometries, making it a preferred choice among vertical machine suppliers seeking robust heavy-duty solutions in integrated CNC machining lines.

Product Advantages

Structural and Design Superiority for Heavy-Duty Durability

The HT06Y series incorporates an integrally cast tailstock and sub-spindle rail enhancing structural stability, ideal for heavy-duty turning work. The reinforced bed employs finite element analysis to optimize rib placement, minimizing deformation and maintaining prolonged accuracy. A 45° inclined saddle equipped with multiple large roller linear guides ensures precise linear motion with minimal backlash. The machine’s modular servo tool turret design featuring 12 to 16 stations supports flexible tool changeover, and compatibility with the Turn-Mill option reflects advanced design thinking typical from premier cnc machine dealers. Such architectural choices improve component lifespan and machining consistency under high load conditions.

Enhanced Performance and Operational Efficiency for Production Facilities

High spindle speed combined with robust 7.5/11 kW motor output ensures rapid material removal rates without sacrificing precision, optimizing throughput for shops specializing in large workpieces. Rapid feed rates up to 30 m/min on X and Z axes improve cycle times significantly. The programmable tailstock and Y-axis interpolation further enhance the operator’s ability to perform complex part geometries with minimal manual intervention, increasing overall shop efficiency. These performance traits position the HT06Y-350/550/750 as a strategic asset within CNC manufacturing processes aiming for predictable quality and minimized downtime, meeting rigorous demands for heavy machining center reliability.

Machine Characteristics The HT series is a heavy-duty turret turning center, specifically designed for heavy cutting of large discs and shafts. The tailstock and sub-spindle rail parts are all integrally cast and have undergone reinforcement and optimization treatment. The extra-wide bed is more conducive to improving processing stability and is particularly suitable for turning and milling compound processing requirements. The 45° inclined saddle, combined with large-sized roller linear guides and precision-grade ball screws, enables it to handle various processing tasks and maintain the bed accuracy for a long time. By applying finite element analysis (FEM), the shape and position of the reinforcing ribs in the castings are optimized to achieve the best bed strength, making the bed structure more suitable for heavy cutting and extending the tool's service life.

■  Specifications

■  Expandable functions of machine tools

Turn-Mill    The entire HT series can be equipped with a servo power tool turret to achieve the processing capability of turning and milling compound functions.

Programmable Tailstock   The machine can be configured with a servo turret or customized with multiple power heads to deliver high-end turning-milling capabilities. This versatile solution meets complex machining demands while minimizing customers' capital expenditure on equipment.

Use Scenarios

Heavy Industrial Shaft and Disc Turning in Automotive and Heavy Equipment Production

In the automotive and heavy equipment sectors, large shafts and discs demand heavy cutting capability and precision dimensional control. The HT06Y-350/550/750 provides a reliable solution, allowing high-volume turning operations with a maximum swing diameter of 600 mm and machining lengths up to 750 mm. Its integrated tailstock and sub-spindle keep high stability under aggressive cutting loads, ensuring tight tolerance production. The availability of Turn-Mill options fits well into automated assembly lines where sequential cutting and milling reduce metal handling. This machine integrates smoothly with existing cnc machining center for sale platforms, enhancing throughput and reducing production bottlenecks in such demanding industrial contexts.

Multi-Functional Turn-Mill Operations in Advanced CNC Manufacturing Facilities

Facilities specializing in complex part profiles benefit from the HT06Y-350/550/750’s multi-axis turning and milling capabilities. The servo tool turret and interpolated Y-axis motion enable machinists to program intricate contours and features in a single setup. This flexibility is paramount in prototyping stages and first-article runs of large diameter components requiring precise, repeatable outcomes. As a product from an experienced cnc machine factory, it upholds stringent quality control standards ensuring compatibility with industry automation and inspection systems. Integration into CNC manufacturing workflows promotes seamless transitions between part setups, reducing lead times while retaining machining accuracy.

FAQ

What sizes and machining capacities does the HT06Y-350/550/750 support?

The HT06Y-350/550/750 series supports a maximum swing diameter of 600 mm and a machining diameter of up to 380 mm. It offers machining lengths of 350, 550, and 750 mm, suitable for large discs and shafts. This flexibility allows us to meet diverse heavy-duty turning needs efficiently.

Can you customize the HT06Y machine for specific turning-milling operations?

Yes, we offer programmable tailstock and Turn-Mill expansion options. These features enable combined turning and milling tasks, allowing your production of complex parts to be more versatile. As specialized cnc turning manufacturers, we tailor solutions to fit your application precisely.

What support do you provide for installation and maintenance of your CNC machines?

We supply detailed technical documentation and 24-hour lifetime technical support to ensure smooth installation and operation. Our after-sales service includes a one-year warranty and ongoing assistance, making us a reliable cnc machine dealer for your industrial equipment needs.

What payment terms and shipping options are available when purchasing from you?

For orders, we usually require a 30% advance payment with the balance due against the bill of lading. Common payment methods include T/T and L/C. Shipping terms such as FOB, CIF, or CNF can be confirmed during the quotation process to align with your logistics preferences.
