HT08ZY-300/500/700

Functional Positioning for Advanced Turning and Milling Integration

The HT08ZY-300/500/700 CNC turning center is engineered for manufacturing environments requiring high precision combined turning and milling capabilities within a single machine. Targeted at professional users such as industrial manufacturers and CNC turning manufacturers, this equipment supports complex component production with flexible setup options. Its motor-directly-driven gantry Y-axis tool turret enhances milling rigidity and positioning accuracy, facilitating prototypes and short-run production of metal parts. The inclusion of a versatile 12-station servo tool turret alongside a large 10-inch chuck allows efficient handling of diverse workpieces, making it suitable for integration into streamlined CNC manufacturing workflows requiring multipurpose machining solutions.

Technical Features Ensuring Precision and Robust Performance

Equipped with a powerful spindle motor rated at 11 to 15 kW and a spindle capable of speeds up to 6000 r/min, this machine delivers substantial cutting capacity across various materials. The axis travels include ±55 mm on the ZY-axis, 260 mm on the X-axis, and multiple Z-axis travel options (450/650/850 mm), providing a generous working envelope for complex turning tasks. Rapid feed rates of 25 m/min on the X and Z axes combined with 34.5 N.m motor torque ensure high machining efficiency. The fully enclosed stainless steel inner protective layout guarantees machine durability by protecting sensitive components from oil and coolant exposure. Optional programmable servo or hydraulic tailstocks further enhance flexibility for machining longer or more intricate parts, aligning with the precise demands of CNC machine dealers and cnc machine factories.

Industry Application and Real-World Operational Value

This CNC turning center is particularly effective in sectors requiring precise multi-process machining such as automotive components, aerospace prototype development, and precision mechanical assemblies. The machine’s capability to perform limited milling alongside turning operations reduces setup time and increases production accuracy, making it valuable for in-house tool-path development and rapid process validation. The robust bed and guidance systems satisfy stringent industrial quality standards and are suitable for integration within automated production lines. Additionally, its adaptability to longer workpieces via programmable tailstock options supports a range of production scales, supporting the operational needs of vertical machine suppliers and companies engaged in integrated cnc manufacturing systems.

Structural and System Design Superiority

The HT08ZY series features a structurally optimized bed and a motor-directly-driven gantry Y-axis tool turret that significantly improves milling rigidity and Y-axis positioning accuracy, addressing the challenges faced by conventional turning centers. Its 12-station servo tool turret ensures rapid tool indexing and machining versatility, enabling multi-process operations on one setup. The fully enclosed stainless steel inner protective layout protects internal components from coolant and debris, enhancing machine longevity and reducing maintenance intervals. Built with high-grade HT300 castings that undergo tempering and natural aging, this cnc lathe benefits from stable dimensional accuracy and resistance to thermal deformation. These design elements collectively support precision-driven manufacturing environments operated by cnc turning manufacturers and cnc machine dealers demanding durable, consistently accurate equipment.

Enhanced Performance, Usability, and Operational Value

Performance-wise, the machine is engineered to maintain consistent high-speed spindle performance up to 6000 r/min powered by an 11/15 kW motor that ensures effective cutting across a broad material spectrum. The rapid feed rates on X and Z axes shorten machining cycles while preserving precision, thereby increasing overall throughput. User operability is augmented via programmable servo or hydraulic tailstock options that provide stable workpiece support for longer components, enhancing process flexibility. The integration of a 12-station tool turret reduces setup changes and downtime, yielding higher ROI by enabling single-machine multi-process manufacturing. These attributes position the unit as a reliable asset for precision cnc mill and cnc lathe operations tailored to meet stringent industrial production benchmarks.

Machine Characteristics ZY series models use a motor-directly-driven gantry Y-axis tool turret, ensuring Y-axis positioning accuracy, milling rigidity, and long-term machine accuracy.

■  Specifications

■  Expandable functions of machine tools

Programmable servo or hydraulic tailstock XT/W, HT series tailstock models can be optionally equipped with programmable tailstocks that are either servo-driven or hydraulic based on the specific demands of the customer's products. They support starting and stopping at any position, and the clamping pressure is adjustable, which is capable of meeting the requirements of refined processing.

Fully enclosed stainless steel inner protective layout The entire series employs a fully-enclosed stainless steel inner protective sheet metal design. Its scientific layout, precision engineering, and superior sealing ensure reliable waterproof and oil-resistant performance during operation.

Use Scenarios

Prototype and Short-Run Production in Automotive Manufacturing

Within automotive component manufacturing environments, the HT08ZY series supports prototype and short-run production through its integrated milling and turning capability. This reduces part handling and secondary operations by facilitating multiple process steps in one machine, critical for fast iteration cycles in prototyping. The Y-axis tool turret’s high positional accuracy combined with the robust spindle motor and sizable 10-inch chuck provides effective machining of complex parts like engine components and transmission gears. Its programmable tailstock option further supports the machining of longer, slender parts, ensuring compliance with strict dimensional tolerances. The machine’s rapid feeds and reliable protective layout facilitate consistent operation in demanding automotive manufacturing workflows, making it a preferred choice among cnc machine factories focusing on efficiency and precision.

Component Development and Validation in Aerospace Engineering

In aerospace and precision mechanical assembly environments, the HT08ZY CNC turning center is utilized for complex turned parts requiring secondary milling features without transferring components between machines. The advanced gantry Y-axis tool turret delivers milling rigidity and precise positioning necessary for features that impact aerodynamic performance or structural integrity. Its comprehensive axis travels accommodate varied part sizes, while the high spindle speed and torque support lightweight alloys and high-strength metals common in aerospace applications. Integration within existing cnc manufacturing lines is facilitated by the machine’s flexible tooling setup and programmable tailstock, enabling reliable, high-accuracy component development and validation. This minimizes lead times and optimizes manufacturability for critical aerospace parts.

FAQ

What types of materials can the HT08ZY-300/500/700 CNC turning center process?

Our HT08ZY series machines are designed to handle a wide range of materials, including various metals suitable for turning and limited milling operations. With a spindle power of up to 15 kW and speeds of 6000 r/min, this CNC machining center for sale is optimized for efficient cutting of steel, aluminum, and other common industry materials.

Can you customize the HT08ZY model to fit specific production needs?

Yes, we offer customization options such as a programmable servo or hydraulic tailstock (XT/W) to accommodate longer or more complex workpieces. Our modular design and versatile 12-station servo tool turret allow integration of additional tooling as needed for your application, making it a flexible solution from our CNC machine factory.

Do you provide installation and technical support after purchase?

We provide comprehensive after-sales service, including a one-year warranty and 24-hour technical support. Our team can assist with installation guidance and troubleshooting remotely. This support ensures that your CNC turning manufacturer equipment remains reliable throughout your production cycles.

What logistics options and payment terms do you offer for purchasing your machines?

We work with FOB, CIF, and CNF shipping terms and typically require a 30% advance payment with the balance due after the bill of lading. We accept T/T payments, and L/C is also available upon request. Contact us for more details or to discuss specific requirements related to buying a vertical machining center for sale or any other equipment.
