■ Specifications
| Machine Type |
ST46 |
| 最大回转直径 Max. swing diameter |
500mm |
| 拖板上最大加工直径 Max. machining diameter on the saddle |
140mm |
| 最大棒料直径 Max. bar through diameter |
38mm |
| 主轴端部形式 Spindle nose |
A2-5 |
| 主轴电机功率 Spindle motor power |
5.5KW |
| 主轴孔直径 Spindle bore |
48mm |
| 主轴最高转速 Max. spindle speed |
4000r/min |
| X轴行程 X axis |
415mm |
| Z轴行程 Z axis |
340mm |
| X轴快速进给速度 X axis rapid feed speed |
25m/min |
| Z轴快速进给速度 Z axis rapid feed speed |
25m/min |
| X轴电机最大转矩 X axis Max. torque of motor |
18N.m |
| Z轴电机最大转矩 Z axis Max. torque of motor |
18N.m |
| 气动夹紧 Pneumatic clamping |
后拉式弹簧筒夹Spring collet |
| 手动卡盘 Manual chuck |
8” |
| 液压夹紧Hydraulic clamping卡盘尺寸 Chuck Size |
8” |
4工位电动刀架
4-station electric knife holder
刀方规格 OD tool size |
20x20mm |
| Machine size (L x W x H) |
1650x1420x1650mm |
| Standard weight |
1850KG |
■ Expandable functions of machine tools
Customized power head configurations can be added according to the customer's part processing requirements, enabling drilling, milling, tapping, and other feature machining operations.
The machine can be configured with a servo turret or customized with multiple power heads to deliver high-end turning-milling capabilities. This versatile solution meets complex machining demands while minimizing customers' capital expenditure on equipment.
Unmatched Precision and DurabilityThe Shanjmc ST46 is a high-precision CNC lathe machine engineered for industrial excellence. Crafted with a robust HT300 grade cast iron bed, this CNC lathe ensures exceptional stability and durability, making it a top choice among cnc lathe suppliers and cnc lathe manufacturers. The monolithic casting undergoes vibration aging and double tempering treatments, eliminating residual stresses for superior dimensional stability. This guarantees consistent machining accuracy, even during extended operations, making the ST46 an ideal cnc lathe for sale for those seeking reliability in heavy-duty cutting tasks.Superior Performance for Complex MachiningBuilt with a low center of gravity, the ST46's monoblock bed structure is optimized using Finite Element Analysis (FEM) to enhance rigidity. This design ensures the cnc lathe machine delivers outstanding performance in demanding cutting operations, extending tool service life. The ST46 is equipped with a 5.5KW spindle motor, achieving speeds up to 4000r/min, and features a 4-station electric knife holder for versatile tooling options. As a leading choice among cnc lathes for sale, it offers expandable functions like modular power heads, enabling drilling, milling, and tapping, thus meeting diverse machining needs with precision.Scalable Solutions for Evolving NeedsThe ST46 is not just a cnc lathe machine; it's a scalable solution designed to adapt to your growing demands. With customizable power head configurations, this cnc lathe can be tailored to specific part processing requirements, offering high-end turning-milling capabilities. This adaptability makes it a preferred option for cnc lathe manufacturers looking to minimize capital expenditure while maximizing operational efficiency. Whether you're a small business or a large-scale operation, the ST46 provides the flexibility and performance needed to stay ahead in the competitive machining landscape. Explore the potential of this cnc lathe for sale and elevate your production capabilities today.
Product Advantages
1. Unmatched Precision and Durability
The Shanjmc ST46 is a high-precision CNC lathe machine designed for industrial excellence. Its robust HT300 grade cast iron bed ensures exceptional stability and durability, making it a top choice among cnc lathe suppliers and cnc lathe manufacturers. The monolithic casting undergoes vibration aging and double tempering treatments, eliminating residual stresses for superior dimensional stability. This guarantees consistent machining accuracy, even during extended operations, making the ST46 an ideal cnc lathe for sale for those seeking reliability in heavy-duty cutting tasks.2. Superior Performance for Complex Machining
Built with a low center of gravity, the ST46's monoblock bed structure is optimized using Finite Element Analysis (FEM) to enhance rigidity. This design ensures the cnc lathe machine delivers outstanding performance in demanding cutting operations, extending tool service life. Equipped with a 5.5KW spindle motor, achieving speeds up to 4000r/min, and featuring a 4-station electric knife holder, it offers versatile tooling options. As a leading choice among cnc lathes for sale, it meets diverse machining needs with precision.3. Scalable Solutions for Evolving Needs
The ST46 is not just a cnc lathe machine; it's a scalable solution designed to adapt to your growing demands. With customizable power head configurations, this cnc lathe can be tailored to specific part processing requirements, offering high-end turning-milling capabilities. This adaptability makes it a preferred option for cnc lathe manufacturers looking to minimize capital expenditure while maximizing operational efficiency. Explore the potential of this cnc lathe for sale and elevate your production capabilities today.4. Versatile Machining Capabilities
The ST46 offers expandable functions like modular power heads, enabling drilling, milling, and tapping. This versatility makes it a top choice among cnc lathes for sale, meeting diverse machining needs with precision. Whether you're a small business or a large-scale operation, the ST46 provides the flexibility and performance needed to stay ahead in the competitive machining landscape.5. Cost-Effective Investment
Investing in the Shanjmc ST46 means choosing a cnc lathe machine that offers both reliability and scalability. Its robust construction and adaptable features ensure long-term operational efficiency, making it a cost-effective choice for cnc lathe manufacturers and cnc lathe suppliers. With the ST46, you can maximize your ROI while minimizing capital expenditure, making it an ideal cnc lathe for sale for businesses aiming to enhance their machining capabilities.
About Us
Shanjmc is a leading manufacturer in the CNC lathe industry, renowned for its commitment to precision engineering and industrial excellence. Our ST-Series, including the ST46, exemplifies our dedication to delivering high-performance machinery that meets the rigorous demands of modern manufacturing. With a robust HT300 grade cast iron bed, our machines offer exceptional stability and durability, ensuring consistent machining accuracy even during extended operations. We employ advanced techniques such as vibration aging and double tempering treatments to eliminate residual stresses, guaranteeing superior dimensional stability. Our innovative designs, optimized using Finite Element Analysis (FEM), enhance rigidity and performance in heavy-duty cutting operations, extending tool service life. At Shanjmc, we understand the evolving needs of our clients, offering scalable solutions with customizable power head configurations for diverse machining tasks. Whether you're a small business or a large-scale operation, our CNC lathes provide the flexibility and efficiency needed to excel in the competitive machining landscape. Explore our range of products and discover how Shanjmc can elevate your production capabilities today.
Contact Shanjmc today to upgrade your industrial operations with the unmatched precision and durability of the ST46 CNC lathe. Let’s enhance your machining capabilities!
FAQ
Who are we?We are Hubei Shangjie Precision Machinery Manufacturing Co., Ltd., a leading manufacturer and supplier of high-precision CNC lathe machines, dedicated to providing industrial excellence through innovative machining solutions.How can we guarantee quality?Our CNC lathes are crafted with robust HT300 grade cast iron beds, ensuring exceptional stability and durability. Each machine undergoes rigorous testing and quality control processes to guarantee consistent machining accuracy and reliability.What can you buy from us?You can purchase a wide range of CNC lathe machines, including the ST46 model, which offers unmatched precision and versatile machining capabilities for industrial applications.Why should you buy from us not from other suppliers?Our ST46 CNC lathe stands out due to its superior performance in heavy-duty cutting operations and expandable functions like modular power heads. We offer scalable solutions tailored to your specific needs, ensuring maximum operational efficiency.What services can we provide?We provide tailor-made automation solutions, comprehensive customer support, and customizable machine configurations to meet diverse machining requirements.Can I customize this product for my business?Yes, the ST46 CNC lathe offers customizable power head configurations, allowing you to tailor the machine to specific part processing requirements and enhance your production capabilities.How fast can I receive my order?We strive to ensure prompt delivery of your CNC lathe machine. Once your order is confirmed, we will provide an estimated delivery timeline based on your location and order specifications.
