XT05WZY-300/500

Precision Turning Solution for Specialized Manufacturing

The XT05WZY-300/500 is engineered as a compact CNC lathe designed for high-precision turning applications, catering primarily to engineering firms, CNC turning manufacturers, and precision parts suppliers. This machine addresses requirements for accurate Y-axis tool turret positioning with a motor-directly-driven gantry design, supporting complex geometries and multi-axis operations. Its compatibility with 6-inch hydraulic and servo chucks along with programmable tailstock options make it suitable for production environments demanding repeatability and process reliability in both small-run and batch CNC machining center operations.

Advanced Technical Specifications and Performance Capabilities

Featuring a 12-station Servo Tool Turret and a spindle nose rated A2-5 powered by 5.5/7.5 kW motors up to 6000 rpm, this lathe ensures robust spindle performance and fast material removal. The machine provides an X-axis travel of 230 mm and Z-axis travel options of 380 mm or 580 mm depending on the model, paired with rapid feeds of 25 m/min on both axes and high motor torque values (25.2 N.m on X/Z and 34.5 N.m on Y-axis). Its fully enclosed stainless steel protective layout supports waterproof and oil-resistance, contributing to durable CNC machine reliability in manufacturing environments. Programmable expandable tailstock options enhance adaptability for refined component processing.

Industrial Integration and Application Value Across Sectors

Ideal for precision component production and prototyping in industries such as automotive, aerospace, and precision equipment manufacturing, the XT05WZY-300/500 supports tight tolerance requirements and efficient changeovers. Its gantry Y-axis turret system delivers high rigidity and accuracy essential for repeated operations, while the 12-station tool turret allows versatile tooling for multifaceted turning and milling tasks. Integration into automated lines or CNC machining centers leads to improved workflow efficiency and reduced setup times, thereby optimizing output quality and process consistency for CNC machine dealers and system integrators.

Product Advantages

Design and Structural Advantages Tailored to Precision Machining

The XT05WZY-300/500 incorporates a motor-directly-driven gantry Y-axis tool turret, which enhances rigidity and positioning precision in the Y-axis, critical for multi-axis CNC lathe operations. The modular 12-station Servo Tool Turret offers flexible tooling arrangements allowing for simultaneous tool indexing and complex machining sequences. The machine’s fully enclosed stainless steel inner protective layout ensures resistance to contamination, thereby extending service life and reducing downtime. This integration of robust mechanical design and protective systems reflects manufacturing-grade engineering common in established CNC machine factories and vertical machine suppliers.

Operational Performance and Value for CNC Turning Manufacturers

With spindle power options up to 7.5 kW and maximum speeds reaching 6000 rpm, the XT05WZY-300/500 consistently delivers high spindle torque and rapid feed rates facilitating efficient material removal and smooth finishing. The compact size combined with programmable tailstock customization improves ease of use and precision in complex part production scenarios. This lathe offers CNC machine dealers and manufacturing engineers reliable performance, supporting quick job changeovers and long-term positional repeatability, enabling improved operational throughput and return on investment in CNC manufacturing facilities.

Machine Characteristics ZY series models use a motor-directly-driven gantry Y-axis tool turret, ensuring Y-axis positioning accuracy, milling rigidity, and long-term machine accuracy.

■  Specifications

■  Expandable functions of machine tools

Programmable servo or hydraulic tailstock XT/W, HT series tailstock models can be optionally equipped with programmable tailstocks that are either servo-driven or hydraulic based on the specific demands of the customer's products. They support starting and stopping at any position, and the clamping pressure is adjustable, which is capable of meeting the requirements of refined processing.

Fully enclosed stainless steel inner protective layout The entire series employs a fully-enclosed stainless steel inner protective sheet metal design. Its scientific layout, precision engineering, and superior sealing ensure reliable waterproof and oil-resistant performance during operation.
